| Basic standard group (BSG) | DIN 338 |
| Brand | Dormer |
| Coating | Bright/TiN |
| Connection diameter - millimeter (DCON MS) | 13.5 mm |
| Country of origin | Brazil |
| Cutting diameter - inch (DC) | 0.5315 inch |
| Cutting diameter - millimeter (DC) | 13.5 mm |
| Cutting diameter tolerance class (TCDC) | h8 |
| Hand (Cutting direction) | Right |
| Length chip flute - millimeter (LCF) | 108 mm |
| Material Application Priority Usage | K - Cast Iron, N - Non-ferrous metals, P - Steel a |
| Material code (BMC) | High Speed Steel |
| Package Dimensions | 17 x 160 x 17 mm |
| Package Quantity | 1 |
| Point Angle (SIG) | 118 ° |
| Sellable Unit Weight | 126.5 g |
| Shank | Cylindrical shank |
| Spiral form | Standard Spiral |
